Aircel VF-125 Non-Cycling Refrigerated Air Dryer
Aircel VF Series AG3022901 Non-Cycling Refrigerated Air Dryer, 115 VAC, 1.05 kW, 3/4 hp, 1 in Inlet Connection
Aircel VF Series AG3022901 Non-Cycling Refrigerated Air Dryer, 115 VAC, 1.05 kW, 3/4 hp, 1 in Inlet Connection AG3022901- Brand Name: Aircel
- Part Number: AG3022901
- Check Stock
-
$4246.00
Add To Favorites List
The Aircel VF Series offers high efficiency air drying at varying flow conditions in a lightweight, compact design. The VF utilizes a three step process to thoroughly remove condensed moisture from the chilled compressed air.
Aircel Non-Cycling Refrigerated Air Dryer, 115 VAC, 60 Hz Frequency, 1 Phase, 1.05 kW Power, HP Rating: 3/4 hp, 1 in Inlet Connection, 1 in Outlet Connection, Inlet Air Temperature: 100 deg F, Air Flow Rate: 125 scfm, 100 psig Air Pressure, Dew Point Temperature: 38 deg F, 100 deg F Maximum Temperature, Refrigerant Type: R-134A, Timer Drain, 22 in Overall Height, 24 in Overall Width, 18 in Overall Depth
| Air Flow Rate | : | 125 scfm |
| Air Pressure | : | 100 psig |
| Dew Point Temperature | : | 38 deg F |
| Drain Type | : | Timer |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 3/4 hp |
| Inlet Air Temperature | : | 100 deg F |
| Inlet Connection Size | : | 1 in |
| Maximum Temperature | : | 100 deg F |
| Outlet Connection Size | : | 1 in |
| Overall Depth | : | 18 in |
| Overall Height | : | 22 in |
| Overall Width | : | 24 in |
| Phase | : | 1 |
| Power Rating | : | 1.05 kW |
| Refrigerant Type | : | R-134A |
| Voltage Rating | : | 115 VAC |
- Internal high efficiency separator
- NEMA 1 standard
