Apollo Valves 10-605-10 Safety Relief Valve
Apollo® Valves 10-600 1060510 Safety Relief Valve, 1 in Nominal, FNPT Connection, 15 to 160 psi Pressure, 0 to 250 deg F
Apollo® Valves 10-600 1060510 Safety Relief Valve, 1 in Nominal, FNPT Connection, 15 to 160 psi Pressure, 0 to 250 deg F 10-605-10- Brand Name: Apollo® Valves
- Part Number: 10-605-10
- UPC: 670750878688
- Check Stock
-
$428.00
Add To Favorites ListASME Section IV capacity certified bronze safety relief valve for protection of hot water heating boilers, systems and similar equipment. It can be pre-set to any pressure ranging from 15 to 160 psig (1 to 11 bar) at 250 deg F (121 deg C) max.
Apollo® Valves Safety Relief Valve, Series: 10-600, 1 in Nominal, FNPT Connection, 15 to 160 psi, Brass/Bronze/Alloy Steel Trim, Silicone Softgoods, Bronze Body, 0 to 250 deg F, 6.7 in Height, 4 in Width, Domestic/Import: Domestic
| Body Material | : | Bronze |
| Connection Type | : | FNPT |
| Domestic/Import | : | Domestic |
| Height | : | 6.7 in |
| Nominal Size | : | 1 in |
| Pressure Rating | : | 15 to 160 psi |
| Series | : | 10-600 |
| Softgoods Material | : | Silicone |
| Temperature Rating | : | 0 to 250 deg F |
| Trim Material | : | Brass/Bronze/Alloy Steel |
| Width | : | 4 in |
- ASME Section IV certified capacity
- Corrosion-resistant construction
- Diaphragm isolated spring chamber
- Extremely high capacity
- Made in USA
Instruction/Installation Manual
