Apollo Valves 4A-106-T2 Double Check Valve With Standard Ball Valve
Apollo® Valves DC4A 4A-106-T2 Double Check Valve With Standard Ball Valve, 1-1/4 in Nominal, Push-To-Connect Connection
Apollo® Valves DC4A 4A-106-T2 Double Check Valve With Standard Ball Valve, 1-1/4 in Nominal, Push-To-Connect Connection 4A-106-T2- Brand Name: Apollo® Valves
- Part Number: 4A-106-T2
- Check Stock
Add To Favorites ListThe Apollo® model DC4A double check valves prevent contamination of the potable water supply due to back-siphonage or backpressure from substances that are objectionable to the potable water supply, but non-health hazards. The top accessed modular check valve cartridges provide captured springs, replaceable seats and reversible silicone seat discs. This made in America assembly features Apollo® ball valves with stainless steel handles and nuts as standard and carries the five-year Apollo® factory warranty.
Apollo® Valves Double Check Valve, Series: DC4A, 1-1/4 in Nominal, Connection Type: Push-To-Connect, 175 psi, 33 to 180 deg F, Water Media, 18-5/8 in L Inlet to Outlet, 4-1/2 in Top to Inlet Center, Bronze Body, Silicone Disc, 300 Stainless Steel Trim, 300 Stainless Steel Handle, Bronze Ball, EPDM Softgoods
| Ball Material | : | Bronze |
| Body Material | : | Bronze |
| Connection Type | : | Push-To-Connect |
| Disc Material | : | Silicone |
| Handle Material | : | 300 Stainless Steel |
| Inlet to Outlet Length | : | 18-5/8 in |
| Media | : | Water |
| Nominal Size | : | 1-1/4 in |
| Pressure Rating | : | 175 psi |
| Series | : | DC4A |
| Softgoods Material | : | EPDM |
| Temperature Rating | : | 33 to 180 deg F |
| Top to Inlet Center | : | 4-1/2 in |
| Trim Material | : | 300 Stainless Steel |
- Low pressure loss documented by independent approval agencies
- Easily removable modular check valve cartridge
- Captured stainless steel springs
- Apollo® ball valves with stainless steel handles and nuts standard
- Top-mounted test cocks for easy testing
- No special tools are required
- Chloramine-resistant elastomers
