Apollo® Valves 72-103-01A 72-103-01A

Apollo Valves 72-103-01A Two-Piece High Pressure Ball Valve

Apollo® Valves 72-100-A Series 72-103-01A Two-Piece High Pressure Ball Valve, 1/2 in Nominal, FNPT Connection

Apollo® Valves 72-100-A Series 72-103-01A Two-Piece High Pressure Ball Valve, 1/2 in Nominal, FNPT Connection 72-103-01A

Apollo® Valves Two-Piece High Pressure Ball Valve, Series: 72-100-A Series, 1/2 in Nominal, FNPT Connection, Full Port, 3000 psi, Lever Handle Actuator, 2.78 in Inlet to Outlet Length, 2.09 in Top to Inlet Center, 0.62 in Opening, 26 Cv Flow Coefficient (Cv), ASTM A105, ASTM A108, ASTM A276 Material Standard, Carbon Steel Body, RPTFE Seat, Carbon Steel Stem, RPTFE Seal, MPTFE Packing, Steel Handle, Carbon Steel Ball, Domestic/Import: Domestic

Actuator Type      :      Lever Handle
Ball Material      :      Carbon Steel
Body Material      :      Carbon Steel
Connection Type      :      FNPT
Domestic/Import      :      Domestic
Flow Coefficient (Cv)      :      26 Cv
Handle Material      :      Steel
Inlet to Outlet Length      :      2.78 in
Material Standard      :      ASTM A105, ASTM A108, ASTM A276
Nominal Size      :      1/2 in
Opening Size      :      0.62 in
Packing Material      :      MPTFE
Port Type      :      Full
Pressure Rating      :      3000 psi
Seal Material      :      RPTFE
Seat Material      :      RPTFE
Series      :      72-100-A Series
Stem Material      :      Carbon Steel
Top to Inlet Center      :      2.09 in
  • Forged body design
  • Reinforced seats
  • Zinc phosphate corrosion protection
  • Adjustable packing gland
  • Blowout-proof stem
  • Heavy-duty lever
  • 150 psig saturated steam
