Apollo® Valves 77C-244-01A 77C-244-01A

Apollo Valves 77C-244-01A 2-Piece Ball Valve

Apollo® Valves 77C-A Series 77C-244-01A 2-Piece Ball Valve, 3/4 in Nominal, Solder Connection, 150 psi, 600 psi Pressure

Apollo® Valves 77C-A Series 77C-244-01A 2-Piece Ball Valve, 3/4 in Nominal, Solder Connection, 150 psi, 600 psi Pressure 77C-244-01A

The Apollo® 77C-A "contractor Series" ball valve features a dezincification-resistant bronze body, premium RPTFE seats and stem packing and a "solid ball" design that delivers true full port flow performance. Cast and machined in Apollo South Carolina manufacturing plants using proven ASTM materials. Not for use with potable water systems in USA.
Apollo® Valves 2-Piece Ball Valve, Series: 77C-A Series, 3/4 in Nominal, Solder Connection, Full Port, 150 psi, 600 psi, Lever Actuator, 3/4 in Orifice, 3.2 in Inlet to Outlet Length, 1.91 in Top to Inlet Center, 36 Cv Flow Coefficient (Cv), ASTM B16, ASTM B584 C84400 Material Standard, Bronze Body, RPTFE Seat, Stainless Steel Stem, RPTFE Seal, RPTFE Packing, Steel Handle, Stainless Steel Ball, Lead-Free, 450 deg F, Domestic/Import: Domestic

Actuator Type      :      Lever
Ball Material      :      Stainless Steel
Body Material      :      Bronze
Connection Type      :      Solder
Domestic/Import      :      Domestic
Flow Coefficient (Cv)      :      36 Cv
Handle Material      :      Steel
Inlet to Outlet Length      :      3.2 in
Lead-Free/Contains Lead      :      Lead-Free
Material Standard      :      ASTM B16, ASTM B584 C84400
Nominal Size      :      3/4 in
Orifice Size      :      3/4 in
Packing Material      :      RPTFE
Port Type      :      Full
Pressure Rating      :      150 psi, 600 psi
Seal Material      :      RPTFE
Seat Material      :      RPTFE
Series      :      77C-A Series
Stem Material      :      Stainless Steel
Temperature Rating      :      450 deg F
Top to Inlet Center      :      1.91 in
  • Blowout-proof stem design
  • Adjustable stem packing
  • Full port solid ball design
  • 100% factory tested
  • pdfInstruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Apollo_Valves_77C_244_01A_Instruction_Installation_Manual.pdf
  • pdfLine Drawing https://assets.unilogcorp.com/267/ITEM/DOC/Apollo_Valves_77C_244_01A_Line_Drawing.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Apollo_Valves_77C_244_01A_Specification_Sheet.pdf
