Apollo Valves 78RV224125 Thermal Expansion Relief Valve

Apollo® Valves 78RV224125 Thermal Expansion Relief Valve, 3/4 in Nominal, Solder Connection, 210 deg F

Apollo® Valves 78RV224125 Thermal Expansion Relief Valve, 3/4 in Nominal, Solder Connection, 210 deg F 78RV224125

The lead free Apollo 78-RV series combination water heater isolation valve/IAPMO approved thermal expansion relief device solves two code requirements while saving time, installation space and money! Ideal alternative to expansion tanks in residential plumbing systems. Made in the USA, featuring lead free dezincification resistant brass and bronze materials.
Apollo® Valves Thermal Expansion Relief Valve, 3/4 in Nominal, Solder Connection, 400 lb/sq-in Ball, 125 lb/sq-in Relief Pressure, Lever Actuator, UNS C27451 DZR Brass Body, UNS C89836 Bronze Relief Body, RTFE Seat, UNS C27451 DZR Brass Stem, Chrome-Plated UNS C27451 DZR Brass Ball Trim, RTFE Stem Packing Material, Steel-Plated Plastisol Handle, 210 deg F, 3.6 in L x 2.6 in W x 4.1 in H

Actuator Type      :      Lever
Body Material      :      UNS C27451 DZR Brass Body, UNS C89836 Bronze Relief
Connection Type      :      Solder
Dimensions      :      3.6 in L x 2.6 in W x 4.1 in H
Handle Material      :      Steel-Plated Plastisol
Nominal Size      :      3/4 in
Packing Material      :      RTFE Stem
Pressure Rating      :      400 lb/sq-in Ball, 125 lb/sq-in Relief
Seat Material      :      RTFE
Stem Material      :      UNS C27451 DZR Brass
Temperature Rating      :      210 deg F
Trim Material      :      Chrome-Plated UNS C27451 DZR Brass Ball
  • Relief valve factory set and sealed 125 lb/sq-in maximum
  • RTFE stem bearing
  • UNS C27451 lead-free DZR brass retainer
  • Stainless steel spring relief and silicone rubber seat relief
  • 3/8 in hose barb relief connection
