Apollo® Valves 7A-132-26 7A-132-26

Apollo Valves 7A-132-26 2-Piece Ball Valve

Apollo® Valves 7A-130 Series 7A-132-26 2-Piece Ball Valve, 3/8 in Nominal, NPT Connection, 400 psig Pressure

Apollo® Valves 7A-130 Series 7A-132-26 2-Piece Ball Valve, 3/8 in Nominal, NPT Connection, 400 psig Pressure 7A-132-26

Apollo® Valves 2-Piece Ball Valve, Series: 7A-130 Series, 3/8 in Nominal, NPT Connection, Standard Port, 400 psig, Gas, Water Media, Lever Actuator, 1/2 in Orifice, 2-3/4 in Inlet to Outlet Length, 1.93 in Top to Inlet Center, ASTM A216, ASTM B164 Material Standard, Carbon Steel Body, RPTFE Seat, Ni-Cu Stem, RPTFE Seal, PTFE Packing, 304 Stainless Steel Handle, Ni-Cu Ball, Domestic/Import: Domestic

Actuator Type      :      Lever
Ball Material      :      Ni-Cu
Body Material      :      Carbon Steel
Connection Type      :      NPT
Domestic/Import      :      Domestic
Handle Material      :      304 Stainless Steel
Inlet to Outlet Length      :      2-3/4 in
Material Standard      :      ASTM A216, ASTM B164
Media      :      Gas, Water
Nominal Size      :      3/8 in
Orifice Size      :      1/2 in
Packing Material      :      PTFE
Port Type      :      Standard
Pressure Rating      :      400 psig
Seal Material      :      RPTFE
Seat Material      :      RPTFE
Series      :      7A-130 Series
Stem Material      :      Ni-Cu
Top to Inlet Center      :      1.93 in
  • Chevron style stem packing
  • Investment cast components
  • Zinc phosphate corrosion protection
  • Bolted, adjustable packing gland
  • Vented ball
  • For use with dry chlorine gas and dry liquid
  • Vented, assembled dry, Monel trim (7A)
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Apollo_Valves_7A_133_26_Specification_Sheet.pdf
