ASCO 8210G094HWAC120/60,110/50 8210G094HWAC120/60,110/50

ASCO 8210G094HWAC120/60,110/50 Solenoid Valve

Asco 8210G094HWAC120/60,110/50 Solenoid Valve, 1/2 in Nominal, NPT Connection, 2-Way, 100 psi Pressure

Asco 8210G094HWAC120/60,110/50 Solenoid Valve, 1/2 in Nominal, NPT Connection, 2-Way, 100 psi Pressure 8210G094HWAC120/60,110/50

Asco Solenoid Valve, Series: 8210 Series, 1/2 in Nominal, NPT Connection, 1NC, NPT End, 100 psi, Hot Water Media, Pilot Actuator, 5/8 in Orifice, 2-3/4 in Inlet to Outlet Length, 3.28 in Top to Inlet Center, 120 VAC, 10.1 W, 50/60 Hz, Class F Coil Insulation Class, Copper Coil, 2 Positions, 2-Way, NEMA 1, 2, 3, 3S, 4, 4X Enclosure, Brass Body, EPDM Seat, EPDM Seal, EPDM Disc, EPDM Softgoods, 32 to 104 deg F, 3.84 in H x 2.29 in W, Additional Information: 4 Cv Flow Coefficient

Actuator Type      :      Pilot
Additional Information      :      4 Cv Flow Coefficient
Body Material      :      Brass
Coil Insulation Class      :      Class F
Coil Type      :      Copper
Configuration      :      1NC
Connection Type      :      NPT
Dimensions      :      3.84 in H x 2.29 in W
Disc Material      :      EPDM
Enclosure Type      :      NEMA 1, 2, 3, 3S, 4, 4X
End Type      :      NPT
Frequency Rating      :      50/60 Hz
Inlet to Outlet Length      :      2-3/4 in
Media      :      Hot Water
Nominal Size      :      1/2 in
Number of Ports/Ways      :      2-Way
Number of Positions      :      2
Orifice Size      :      5/8 in
Power Rating      :      10.1 W
Pressure Rating      :      100 psi
Seal Material      :      EPDM
Seat Material      :      EPDM
Series      :      8210 Series
Softgoods Material      :      EPDM
Temperature Rating      :      32 to 104 deg F
Top to Inlet Center      :      3.28 in
Voltage Rating      :      120 VAC
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Asco_8210G094HWAC120_60_110_50_Catalog.pdf
