Browning® AK84H AK84H

Browning AKH AK84H Sheave, Split Taper Bushed Bore, 3/8-1-1/2 in Dia Bore, 3/4 in W Face

Browning® AK84H Sheave, Split Taper Bushed Bore, 3/8 to 1-1/2 in Dia Bore, 3/4 in W Face, 7.66 in Dia Pitch

Browning® AK84H Sheave, Split Taper Bushed Bore, 3/8 to 1-1/2 in Dia Bore, 3/4 in W Face, 7.66 in Dia Pitch AK84H

Browning® Sheave, Series: AKH Series, Split Taper Bushed Bore, 3/8 to 1-1/2 in Bore Diameter, 3L, 4L, A Belt Section, 1 Number of Grooves, 7.66 in Pitch Diameter, 1-1/4 in Length Through Bore, 3/4 in Face Width, For Use With: 4L, a Type V-Belts, Iron, 8-1/4 in OD

Belt Section Size      :      3L, 4L, A
Bore Diameter      :      3/8 to 1-1/2 in
Bore Type      :      Split Taper Bushed
Dimensions      :      8-1/4 in OD
Face Width      :      3/4 in
Length Through Bore      :      1-1/4 in
Material      :      Iron
Number of Grooves      :      1
Pitch Diameter      :      7.66 in
Series      :      AKH Series
Suitable For Use With      :      4L, a Type V-Belts
  • Bushed products provide more flexibility of inventory, by just changing out the bore size of the bushing
  • H Bushing which has a bore range from 3/8 in to 1-1/2 in
  • Combination groove on the BK sheaves can accommodate a wide assortment of belts (4L, 5L, A, AX, B and BX) for maximum flexibility and horsepower range
  • Sheaves provided with the durability of a power coat paint which protects product from rusting in high moisture environments
  • Split taper bushing required
  • H type bushing
  • Plain pulley construction
  • Sheaves are balanced and accurately machined to minimize vibration
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Browning_AK84H_Catalog.pdf
