Cutler-Hammer 10250T476C21-1-POP 10250T476C21-1-POP

Cutler-Hammer 10250T476C21-1-POP Illuminated Pushbutton

Cutler-Hammer 10250T Series 10250T476C21-1-POP Illuminated Pushbutton, 24 VAC/VDC, 1NO-1NC, Momentary Action, IP65

Cutler-Hammer 10250T Series 10250T476C21-1-POP Illuminated Pushbutton, 24 VAC/VDC, 1NO-1NC, Momentary Action, IP65 10250T476C21-1-POP

Cutler-Hammer Illuminated Pushbutton, Series: 10250T Series, 24 VAC/VDC, 1NO-1NC, 10 A Contact, Momentary, Extended Actuator, NEMA 3, 3R, 4, 4X, 12, 13, IP Rating: IP65, Red Actuator Color, Zinc Housing, 30.5 mm Cutout Size, 2-1/2 in Height, 5-1/2 in Width, 6.4 in D, Additional Information: Chrome-Plated Finish

Action Type      :      Momentary
Actuator Color      :      Red
Actuator Type      :      Extended
Additional Information      :      Chrome-Plated Finish
Contact Configuration      :      1NO-1NC
Contact Rating      :      10 A
Cutout Size      :      30.5 mm
Depth      :      6.4 in
Enclosure Type      :      NEMA 3, 3R, 4, 4X, 12, 13
Height      :      2-1/2 in
Housing Material      :      Zinc
IP Rating      :      IP65
Series      :      10250T Series
Voltage Rating      :      24 VAC/VDC
Width      :      5-1/2 in
  • Heavy-duty zinc die-cast construction
  • Enclosed silver contacts with reliability nibs
  • Diaphragm seals with drainage holes
  • Grounding nibs on the operator casing
  • Reliability nibs improve contact reliability even under dry circuit and fine dust conditions
  • Drainage holes prevent build-up of liquid inside the operator which can prevent operation in freezing environments
  • Grounding nibs bite through paint and other coatings to provide secure ground
  • Slow make and break contact operation (positive opening NC contacts) for improved safety
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Cutler-Hammer_10250T476C211POP_Specification_Sheet.pdf
