Cutler-Hammer BWH2100 BWH2100

Cutler-Hammer BWH2100 Main Circuit Breaker

Cutler-Hammer BWH2100 Main Circuit Breaker, 120/240 VAC, 100 A, 25 kA Interrupt, 2-Pole, Thermal Magnetic Trip

Cutler-Hammer BWH2100 Main Circuit Breaker, 120/240 VAC, 100 A, 25 kA Interrupt, 2-Pole, Thermal Magnetic Trip BWH2100

Cutler-Hammer Main Circuit Breaker, 100 A, 120/240 VAC, 25 kA Interrupt Rating, 2 Poles, 1 ph Phase, Thermal Magnetic Trip, Load Lug Terminal, 2 AWG to 300 kcmil Aluminum/Copper Wire, Bolt-On Mounting, 60 to 75 deg C, 5-1/4 in Width, 6-1/4 in Length, 5-1/4 in Height

Amperage Rating      :      100 A
Height      :      5-1/4 in
Interrupt Rating      :      25 kA
Length      :      6-1/4 in
Mounting Type      :      Bolt-On
Number of Poles      :      2
Phase      :      1 ph
Temperature Rating      :      60 to 75 deg C
Terminal Type      :      Load Lug
Trip Type      :      Thermal Magnetic
Voltage Rating      :      120/240 VAC
Width      :      5-1/4 in
Wire Size      :      2 AWG to 300 kcmil Aluminum/Copper
