Cutler-Hammer C25FNF260A C25FNF260A

Cutler-Hammer C25FNF260A Definite Purpose Contactor

Cutler-Hammer C25FNF260A Definite Purpose Contactor, 115 V, 60 A, 50/60 Hz, 110 to 120 VAC Coil, 2 -Pole

Cutler-Hammer C25FNF260A Definite Purpose Contactor, 115 V, 60 A, 50/60 Hz, 110 to 120 VAC Coil, 2 -Pole C25FNF260A

Cutler-Hammer Definite Purpose Contactor, 115 V, 60 A, 50/60 Hz, 110 to 120 VAC Coil Voltage, 75 A Resistive Amperage, 2 Poles, Double Break Contact, Quick-Connect Connection, 60-75A Frame, Box Lug Terminal, 14 to 2 AWG, 14 to 6 AWG Wire, Open Enclosure, 250000 cycles Operating Cycles, Panel Mounting, 150 deg F, 3-3/4 in Height, 2.63 in Width, 3.97 in Depth

Amperage Rating      :      60 A
Coil Voltage      :      110 to 120 VAC
Connection Type      :      Quick-Connect
Contact Type      :      Double Break
Depth      :      3.97 in
Enclosure Type      :      Open
Frame Size      :      60-75A
Frequency Rating      :      50/60 Hz
Height      :      3-3/4 in
Mounting Type      :      Panel
Number of Poles      :      2
Operating Cycles      :      250000 cycles
Resistive Amperage      :      75 A
Temperature Rating      :      150 deg F
Terminal Type      :      Box Lug
Voltage Rating      :      115 V
Width      :      2.63 in
Wire Size      :      14 to 2 AWG, 14 to 6 AWG
  • Designed for service in applications such as refrigeration, air conditioning and resistance heating
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_C320KG1_Catalog.pdf
  • pdfFull Engineering Drawing https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_C25FNF260A_Full_Engineering_Drawing.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_C25FNF260A_Specification_Sheet.pdf
