Cutler-Hammer C361NC C361NC

Cutler-Hammer C361NC Non-Fusible Rotary Disconnect Main Switch

Cutler-Hammer C361NC Non-Fusible Rotary Disconnect Main Switch, 14 to 2 AWG Wire, Flange Mounting

Cutler-Hammer C361NC Non-Fusible Rotary Disconnect Main Switch, 14 to 2 AWG Wire, Flange Mounting C361NC

Cutler-Hammer Non-Fusible Rotary Disconnect Main Switch, 30 A, 7.5 hp, 7.5 hp, 15 hp, 20 hp, 5 hp, 14 to 2 AWG Wire, Flange Mounting, 12.1 in L x 10.3 in W x 8.5 in H, 7 to 16 in Adjustable Depth Additional Information

Additional Information      :      7 to 16 in Adjustable Depth
Amperage Rating      :      30 A
Dimensions      :      12.1 in L x 10.3 in W x 8.5 in H
HP Rating      :      7.5 hp, 7.5 hp, 15 hp, 20 hp, 5 hp
Mounting Type      :      Flange
Wire Size      :      14 to 2 AWG
  • Switch and operating mechanism only
  • Maximum horsepower ratings refer to switch only
  • Does not include handle, must be purchased separately
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_2607D63G02_Catalog.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_C361NC_Specification_Sheet.pdf
