Cutler-Hammer XTPR1P6BC1 CHP-XTPR1P6BC1

Cutler-Hammer CHP-XTPR1P6BC1 Rotary Manual Motor Protector

Cutler-Hammer CHP-XTPR1P6BC1 Rotary Manual Motor Protector, 3/4 hp, 600/347 V, 3 ph -Phase, Screw Terminal

Cutler-Hammer CHP-XTPR1P6BC1 Rotary Manual Motor Protector, 3/4 hp, 600/347 V, 3 ph -Phase, Screw Terminal XTPR1P6BC1

Cutler-Hammer Rotary Manual Motor Protector, 1 to 1.6 A, 600/347 V, 1.1 kW, 3/4 hp, 1 to 1.6 A Contact Rating, 1 to 1.6 A Full Load Current Rating, 3 ph Phase, B Frame, Class 10 Trip, Screw Terminal, 3.66 in Width, 1.93 in Length, 3.74 in Height

Amperage Rating      :      1 to 1.6 A
Contact Rating      :      1 to 1.6 A
Frame Type      :      B
Full Load Current Rating      :      1 to 1.6 A
HP Rating      :      3/4 hp
Height      :      3.74 in
Length      :      1.93 in
Phase      :      3 ph
Power Rating      :      1.1 kW
Terminal Type      :      Screw
Trip Type      :      Class 10
Voltage Rating      :      600/347 V
Width      :      3.66 in
  • XT manual motor protectors are selected based on the overload current range required for a given motor
  • This current range is determined from the motor full load ampere rating and motor service factor usually found on the motor nameplate
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_XTPB016BC1_Catalog.pdf
  • pdfLine Drawing https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_XTPR1P6BC1_Line_Drawing.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_XTPR1P6BC1_Specification_Sheet.pdf
