Cutler-Hammer C Series EHD3090 Circuit Breaker, 480 V, 90 A, 14 kA, 18 kA Interrupt, 3-Pole

Cutler-Hammer C Series EHD3090 Circuit Breaker, 480 V, 90 A, 14 kA, 18 kA Interrupt, 3-Pole EHD3090

Cutler-Hammer Circuit Breaker, C Series, 90 A, 480 V, 50/60 Hz, 14 kA, 18 kA Interrupt Rating, 3 Poles, 3 ph Phase, F Frame, Fixed Thermal, Fixed Magnetic Trip, Load Lug Terminal, Handle Actuator, 14 to 1/0 AWG Wire, Bolt-On Mounting, 40 deg C, 4.13 in Width, 3.38 in Length, 6 in Height

Actuator Type      :      Handle
Amperage Rating      :      90 A
Frame Type      :      F
Frequency Rating      :      50/60 Hz
Height      :      6 in
Interrupt Rating      :      14 kA, 18 kA
Length      :      3.38 in
Mounting Type      :      Bolt-On
Number of Poles      :      3
Phase      :      3 ph
Series      :      C Series
Temperature Rating      :      40 deg C
Terminal Type      :      Load Lug
Trip Type      :      Fixed Thermal, Fixed Magnetic
Voltage Rating      :      480 V
Width      :      4.13 in
Wire Size      :      14 to 1/0 AWG
