Cutler-Hammer FAZ-C1/1-SP FAZ-C1/1-SP

Cutler-Hammer FAZ-C1/1-SP Miniature Circuit Breaker

Cutler-Hammer FAZ Series FAZ-C1/1-SP Miniature Circuit Breaker, 277 V, 1 A, 15 kA Interrupt, 1-Pole, 5-10X Trip

Cutler-Hammer FAZ Series FAZ-C1/1-SP Miniature Circuit Breaker, 277 V, 1 A, 15 kA Interrupt, 1-Pole, 5-10X Trip FAZ-C1/1-SP

Cutler-Hammer Miniature Circuit Breaker, FAZ Series, 1 A, 277 V, 50/60 Hz, Interrupt Rating: 15 kA, Number of Poles: 1, 5-10X Trip, Standard Terminal, DIN Rail Mounting, 1 in W, 0.69 in L, 0.69 in H

Amperage Rating      :      1 A
Frequency Rating      :      50/60 Hz
Height      :      0.69 in
Interrupt Rating      :      15 kA
Length      :      0.69 in
Mounting Type      :      DIN Rail
Number of Poles      :      1
Series      :      FAZ Series
Terminal Type      :      Standard
Trip Type      :      5-10X
Voltage Rating      :      277 V
Width      :      1 in
  • Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices
  • Color coded indicator provides breaker status for easy troubleshooting
  • Captive posidrive terminal screws with finger and back-of-hand protection (IP20)
  • Trip-free design - breaker cannot be defeated by holding the handle in the on position
  • Breaker information printed on the front of the device for quick identification
  • C curve
  • Single package
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_FAZ_C1_1_SP_Catalog.pdf
