Cutler-Hammer FD3025L FD3025L

Cutler-Hammer FD3025L Molded Case Circuit Breaker

Cutler-Hammer C Series FD3025L Molded Case Circuit Breaker, 250/600 VAC/VDC, 25 A, 35 kA, 65 kA Interrupt, 3 -Pole

Cutler-Hammer C Series FD3025L Molded Case Circuit Breaker, 250/600 VAC/VDC, 25 A, 35 kA, 65 kA Interrupt, 3 -Pole FD3025L

Cutler-Hammer Molded Case Circuit Breaker, Series: C Series, 25 A, 250/600 VAC/VDC, 50/60 Hz, Interrupt Rating: 35 kA, 65 kA, Number of Poles: 3, Connection Type: Lug, Frame Type: F, Fixed Magnetic, Fixed Thermal Trip, 4.13 in W, 3.38 in L, 6 in H

Amperage Rating      :      25 A
Connection Type      :      Lug
Frame Type      :      F
Frequency Rating      :      50/60 Hz
Height      :      6 in
Interrupt Rating      :      35 kA, 65 kA
Length      :      3.38 in
Number of Poles      :      3
Series      :      C Series
Trip Type      :      Fixed Magnetic, Fixed Thermal
Voltage Rating      :      250/600 VAC/VDC
Width      :      4.13 in
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_FD3025L_Catalog.pdf
  • pdfInstruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_FD3025L_Instruction_Installation_Manual.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_FD3025L_Specification_Sheet.pdf
  • linkVideo Link https://youtu.be/ZBPV2r7VTgw
