Cutler-Hammer GHB3070 GHB3070

Cutler-Hammer GHB3070 GHB Molded Case Circuit Breaker

Cutler-Hammer C Series GHB3070 GHB Molded Case Circuit Breaker, 480/277 VAC/125/250 VDC, 70 A, 14 kA, 65 kA Interrupt

Cutler-Hammer C Series GHB3070 GHB Molded Case Circuit Breaker, 480/277 VAC/125/250 VDC, 70 A, 14 kA, 65 kA Interrupt GHB3070

Cutler-Hammer GHB Molded Case Circuit Breaker, C Series, 70 A, 480/277 VAC/125/250 VDC, 50/60 Hz, 14 kA, 65 kA Interrupt Rating, 3 Poles, 3 ph Phase, G Frame, Fixed Thermal, Fixed Magnetic Trip, Line and Load Lug Terminal, 10 to 1/0 AWG Wire, Bolt-On Mounting, NEMA Rating: NEMA 4, 40 deg C, 3 in Width, 2.63 in Length, 4 in Height

Amperage Rating      :      70 A
Frame Type      :      G
Frequency Rating      :      50/60 Hz
Height      :      4 in
Interrupt Rating      :      14 kA, 65 kA
Length      :      2.63 in
Mounting Type      :      Bolt-On
NEMA Rating      :      NEMA 4
Number of Poles      :      3
Phase      :      3 ph
Series      :      C Series
Temperature Rating      :      40 deg C
Terminal Type      :      Line and Load Lug
Trip Type      :      Fixed Thermal, Fixed Magnetic
Voltage Rating      :      480/277 VAC/125/250 VDC
Width      :      3 in
Wire Size      :      10 to 1/0 AWG
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_GHB3080_Catalog.pdf
  • pdfInstruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_HFD3080_Instruction_Installation_Manual.pdf
  • videoVideo Link https://www.youtube.com/watch?v=ZBPV2r7VTgw
