Cutler-Hammer HFD2100 HFD2100

Cutler-Hammer HFD2100 Molded Case Circuit Breaker

Cutler-Hammer C Series HFD2100 Molded Case Circuit Breaker, 600 VAC/250 VDC, 100 A, 65 kA, 100 kA Interrupt, 2-Pole

Cutler-Hammer C Series HFD2100 Molded Case Circuit Breaker, 600 VAC/250 VDC, 100 A, 65 kA, 100 kA Interrupt, 2-Pole HFD2100

Cutler-Hammer Molded Case Circuit Breaker, C Series, 100 A, 600 VAC/250 VDC, 50/60 Hz, 65 kA, 100 kA Interrupt Rating, 2 Poles, 1 ph Phase, F Frame, Fixed Thermal, Fixed Magnetic Trip, Load Lug Terminal, Handle Actuator, 14 to 1/0 AWG Wire, Bolt-On Mounting, 40 deg C, 2-3/4 in Width, 3.38 in Length, 6 in Height

Actuator Type      :      Handle
Amperage Rating      :      100 A
Frame Type      :      F
Frequency Rating      :      50/60 Hz
Height      :      6 in
Interrupt Rating      :      65 kA, 100 kA
Length      :      3.38 in
Mounting Type      :      Bolt-On
Number of Poles      :      2
Phase      :      1 ph
Series      :      C Series
Temperature Rating      :      40 deg C
Terminal Type      :      Load Lug
Trip Type      :      Fixed Thermal, Fixed Magnetic
Voltage Rating      :      600 VAC/250 VDC
Width      :      2-3/4 in
Wire Size      :      14 to 1/0 AWG
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_HFD3080_Catalog.pdf
  • pdfFull Engineering Drawing https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_HFD2100_Full_Engineering_Drawing.pdf
  • pdfInstruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_HFD3080_Instruction_Installation_Manual.pdf
  • videoVideo Link https://www.youtube.com/watch?v=ZBPV2r7VTgw
