Cutler-Hammer HMCP030H1C HMCP030H1C

Cutler-Hammer HMCP030H1C HMCP Molded Case Circuit Breaker

Cutler-Hammer C Series HMCP030H1C HMCP Molded Case Circuit Breaker, 600 VAC/250 VDC, 30 A, 65 kAIC Interrupt, 3-Pole

Cutler-Hammer C Series HMCP030H1C HMCP Molded Case Circuit Breaker, 600 VAC/250 VDC, 30 A, 65 kAIC Interrupt, 3-Pole HMCP030H1C

Cutler-Hammer HMCP Molded Case Circuit Breaker, C Series, 30 A, 600 VAC/250 VDC, 50/60 Hz, 65 kAIC Interrupt Rating, 3 Poles, 3 ph Phase, Feed-Thru Connection, J-K Frame, Magnetic Trip, 90 to 300 A Trip Range, Line and Load Lug Terminal, Toggle Actuator, 14 to 1/0 AWG Wire, Free-Standing Mounting, NEMA Rating: NEMA 1, -4 to 158 deg F, Non-Aluminum Terminal, 5 in Width, 8 in Length, 5 in Height

Actuator Type      :      Toggle
Amperage Rating      :      30 A
Connection Type      :      Feed-Thru
Frame Type      :      J-K
Frequency Rating      :      50/60 Hz
Height      :      5 in
Interrupt Rating      :      65 kAIC
Length      :      8 in
Mounting Type      :      Free-Standing
NEMA Rating      :      NEMA 1
Number of Poles      :      3
Phase      :      3 ph
Series      :      C Series
Temperature Rating      :      -4 to 158 deg F
Terminal Material      :      Non-Aluminum
Terminal Type      :      Line and Load Lug
Trip Range      :      90 to 300 A
Trip Type      :      Magnetic
Voltage Rating      :      600 VAC/250 VDC
Width      :      5 in
Wire Size      :      14 to 1/0 AWG
