Cutler-Hammer C Series JD3150 JD Molded Case Circuit Breaker, 600 VAC/250 VDC, 150 A, 35 kA, 65 kA Interrupt, 3-Pole

Cutler-Hammer C Series JD3150 JD Molded Case Circuit Breaker, 600 VAC/250 VDC, 150 A, 35 kA, 65 kA Interrupt, 3-Pole JD3150

Cutler-Hammer JD Molded Case Circuit Breaker, C Series, 150 A, 600 VAC/250 VDC, 50/60 Hz, 35 kA, 65 kA Interrupt Rating, 3 Poles, 3 ph Phase, J Frame, Fixed Thermal, Fixed Magnetic Trip, 250 to 70 A Trip Range, Line and Load Lug Terminal, Toggle Actuator, 4 AWG to 350 kcmil Wire, Bolt-On Mounting, 40 deg C, Aluminum Terminal, 4.13 in Width, 4.06 in Length, 4.13 in Height

Actuator Type      :      Toggle
Amperage Rating      :      150 A
Frame Type      :      J
Frequency Rating      :      50/60 Hz
Height      :      4.13 in
Interrupt Rating      :      35 kA, 65 kA
Length      :      4.06 in
Mounting Type      :      Bolt-On
Number of Poles      :      3
Phase      :      3 ph
Series      :      C Series
Temperature Rating      :      40 deg C
Terminal Material      :      Aluminum
Terminal Type      :      Line and Load Lug
Trip Range      :      250 to 70 A
Trip Type      :      Fixed Thermal, Fixed Magnetic
Voltage Rating      :      600 VAC/250 VDC
Width      :      4.13 in
Wire Size      :      4 AWG to 350 kcmil
