Cutler-Hammer XTPR001BC1 XTPR001BC1

Cutler-Hammer XTPR001BC1 Rotary Manual Motor Protector

Cutler-Hammer XTPR001BC1 Rotary Manual Motor Protector, 1/2 hp, 600/347 V, 3 ph -Phase, Screw Terminal

Cutler-Hammer XTPR001BC1 Rotary Manual Motor Protector, 1/2 hp, 600/347 V, 3 ph -Phase, Screw Terminal XTPR001BC1

Cutler-Hammer Rotary Manual Motor Protector, 1 A, 600/347 V, 0.55 kW, 1/2 hp, 1 A Contact Rating, 0.63 to 1 A Full Load Current Rating, 3 ph Phase, B Frame, Class 10 Trip, Screw Terminal, 3 in Width, 3 in Length, 2 in Height

Amperage Rating      :      1 A
Contact Rating      :      1 A
Frame Type      :      B
Full Load Current Rating      :      0.63 to 1 A
HP Rating      :      1/2 hp
Height      :      2 in
Length      :      3 in
Phase      :      3 ph
Power Rating      :      0.55 kW
Terminal Type      :      Screw
Trip Type      :      Class 10
Voltage Rating      :      600/347 V
Width      :      3 in
  • XT manual motor protectors are selected based on the overload current range required for a given motor
  • This current range is determined from the motor full load ampere rating and motor service factor usually found on the motor nameplate
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_XTPB016BC1_Catalog.pdf
  • pdfLine Drawing https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_XTPR001BC1_Line_Drawing.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Cutler_Hammer_XTPR001BC1_Specification_Sheet.pdf
