Donaldson® P565061 IDI_149684

Donaldson P565061 Hydraulic Filter, Spin-On (OEM)

Donaldson® SP15/25 P565061 Spin-On Hydraulic Filter, #1-12 Port, UN Port Connection, 30 gpm

Donaldson® SP15/25 P565061 Spin-On Hydraulic Filter, #1-12 Port, UN Port Connection, 30 gpm P565061

The SP15/25 series are economical, low pressure filters with spin-on convenience and a wide range of cleanliness ratings. Filters are available with the bypass ratings of your choice - 25 psi, 15 psi, 5 psi or no bypass. Take advantage of our mix and match system of instock heads and filters, so you can get exactly what you need. Choose the media type and configuration that’s best for your application. Options include Donaldson® exclusive Synteq™ , natural fiber cellulose, stainless steel wiremesh or water absorbing media.
Donaldson® Spin-On Hydraulic Filter, Series: SP15/25, #1-12 Port, UN Port Connection, Cellulose Media, 5 um at Beta 2, 24 um at Beta 1000, 30 gpm Flow Rate, 150 psi, -22 to 225 deg F Operating, 3.66 in OD, 5.35 in Overall Height

Flow Rate      :      30 gpm
Media Type      :      Cellulose
Micron Rating      :      5 um at Beta 2, 24 um at Beta 1000
Operating Temperature      :      -22 to 225 deg F
Outside Diameter      :      3.66 in
Overall Height      :      5.35 in
Port Connection Type      :      UN
Port Size      :      #1-12
Pressure Rating      :      150 psi
Series      :      SP15/25
  • The SP15/25 series are economical, low pressure filters with spin-on convenience and a wide range of cleanliness ratings
  • Mix and match system of in stock heads and filters
  • No bypass
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Donaldson_P550274_Catalog.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Donaldson_P565061_Specification_Sheet.pdf
  • linkVideo Link https://youtu.be/DouGwx_ia3o
