EATON BR2020B100V Main Circuit Breaker Load Center

EATON BR2020B100V Main Circuit Breaker Load Center, 120/240 VAC, 100 A, 20-Pole, 10 kA Interrupt

EATON BR2020B100V Main Circuit Breaker Load Center, 120/240 VAC, 100 A, 20-Pole, 10 kA Interrupt BR2020B100V

Specially designed for easy installation, EATON BR 1 in load centers house the branch circuit breakers and the wiring requires to distribute power to individual circuits. They serve as main breaker for service entrances or as main lug when adding circuits to existing service. The main breaker protects the main entire panel and can be used as a service disconnect. The branch breakers protect the wires leading to individual electrical loads such as fixtures and outlets.

Amperage Rating      :      100 A
Breaker Type      :      BR
Dimensions      :      5.19 in L x 14.31 in W x 18.75 in H
Enclosure Type      :      NEMA 1, C1
Interrupt Rating      :      10 kA
Material      :      Metal
Mounting Type      :      Combination
Number of Circuits      :      20
Number of Poles      :      20
Number of Spaces      :      20
Voltage Rating      :      120/240 VAC
Wire Size      :      6 to 1/0 AWG
Wiring Configuration      :      3-Wire
  • Flexible neutral design
  • Tangential main knockout
  • Single key hole mounting
  • Factory pre attached neutral bonding strap
  • Copper/aluminum wire at 60 - 75 deg C for main breakers
  • Standard tin plated aluminum bus for excellent conductivity and corrosion resistance
  • Twin neutral design located in wireway, away from circuit breakers, means easier wiring and balancing of the load
  • Extra 1-1/2 Inch knockout for bundling allows maximum wiring gutter space for ease of wiring in compliance with NEC requirements
  • One piece roll formed metal backpan with circuit breaker alignment notches ensures accurately aligned breaker and bus tabs
  • Standard 14-3/8 Inch Width enclosures fit snugly between wall studs
