Glasfloss® ZPS12241265BO ZPS12241265BO

Glasfloss ZPS12241265BO Air Filter

Glasfloss® Z-PAK ZPS12241265BO Air Filter, Orange Synthetic Media, 12 in W, 24 in H, 12 in D, 11 MERV

Glasfloss® Z-PAK ZPS12241265BO Air Filter, Orange Synthetic Media, 12 in W, 24 in H, 12 in D, 11 MERV ZPS12241265BO

Glasfloss Z-Pak air filters are designed for medium and high efficiency applications and offer superior service life. The Z-Pak's total rigid construction makes it ideal for variable air volume systems (VAV), where changes in air flow can have an adverse affect on non-rigid type filters.
Glasfloss® Air Filter, Series: Z-PAK, Orange Synthetic Media, 12 in Width, 24 in Height, 12 in D, MERV: 11, 60 to 65 % Filter Efficiency, 29.17 sq-ft Media Area, 500 fpm Rated Velocity, 0.32 in-WG Initial Resistance, 1-1/2 in-WG Final Resistance, 11-3/8 x 23-3/8 x 11-1/2 in Actual

Actual Size      :      11-3/8 x 23-3/8 x 11-1/2 in
Depth      :      12 in
Filter Efficiency      :      60 to 65 %
Final Resistance      :      1-1/2 in-WG
Height      :      24 in
Initial Resistance      :      0.32 in-WG
MERV      :      11
Media Area      :      29.17 sq-ft
Media Material      :      Orange Synthetic
Rated Velocity      :      500 fpm
Series      :      Z-PAK
Width      :      12 in
  • Z-Pak Series frame shall be a rigid construction of 26 ga galvanized steel
  • The media shall be a high density synthetic fiber
  • The filter media pack shall be constructed by pleating a continuous sheet of media into uniform spaced pleats, which are separated by flame retardant, injection molded plastic media separators
  • A heavy-duty expanded metal reinforcement shall be laminated to the air exit side of the media by a thermo-setting adhesive to maintain continuity of the radial pleats
  • The expanded metal shall be galvanized to resist rust and corrosion
  • Metal vertical brackets shall be utilized to stabilize the media pack and prevent air bypass
  • Injection molded pleat separators
  • High dust holding capacity
  • The air entry and air exit side shall be fitted with (two) 26 ga support struts
  • The pleated media ends are sealed to the top and bottom of the metal frame to prevent air bypass
  • No gasket
  • Made in the U.S.A
  • For VAV systems
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Glasfloss_ZPS12241265BO_Specification_Sheet.pdf
