Lovejoy® 4J-7/8 4J-7/8

Lovejoy 4J-7/8 Sleeve Coupling Flange, 7/8 Inch Bore, 2.46 Inch OD, 2.38 Inch Length Through Bore, Die-Cast Zinc Alloy

Lovejoy® 4J-7/8 Sleeve Coupling Flange, 7/8 in Bore, 2.46 in OD, 2.38 in L Through Bore, Die-Cast Zinc Alloy

Lovejoy® 4J-7/8 Sleeve Coupling Flange, 7/8 in Bore, 2.46 in OD, 2.38 in L Through Bore, Die-Cast Zinc Alloy 4J-7/8

Lovejoy® Sleeve Coupling Flange, 7/8 in Bore, 2.46 in OD, 2.38 in Length Through Bore, 3/16 x 3/32 in Keyway, 7600 rpm, 120 in-lb Torque, Die-Cast Zinc Alloy, 0.88 in W x 2.460 in H

Bore Size      :      7/8 in
Dimensions      :      0.88 in W x 2.460 in H
Keyway Size      :      3/16 x 3/32 in
Length Through Bore      :      2.38 in
Material      :      Die-Cast Zinc Alloy
Outside Diameter      :      2.46 in
Speed Rating      :      7600 rpm
Torque Rating      :      120 in-lb
  • 0.88 in L through bore
  • 1.63 in hub Dia
  • One over the key and one at 90 deg
  • 1 deg for EPDM rubber inserts, 0.25 deg for H inserts
  • pdfCatalog https://cx1content.unilogcorp.com/cx1/view/api/asset/v1/dam/assets/ITEM/DOC/file/267/Lovejoy_6J_7_8_Catalog.pdf
