MIDLAND INDUSTRIES 46904SS 46904SS

MIDLAND INDUSTRIES 46904SS Miniature Ball Valve, 3/8 in, MIP x FIP, 316 Stainless Steel, 1000 psi WOG, 150 psi WSP

MIDLAND INDUSTRIES 46904SS Miniature Ball Valve, 3/8 in, MIP x FIP, 316 Stainless Steel, 1000 psi WOG, 150 psi WSP

MIDLAND INDUSTRIES 46904SS Miniature Ball Valve, 3/8 in, MIP x FIP, 316 Stainless Steel, 1000 psi WOG, 150 psi WSP 46904SS

MIDLAND INDUSTRIES Miniature Ball Valve, 3/8 in Nominal, MIP x FIP Connection, Standard Port, 1000 psi WOG, 150 psi WSP Pressure, 2.45 in Inlet to Outlet Length, 1-1/2 in Top to Inlet Center, Butterfly Handle Operator, 316 Stainless Steel Body, PTFE Seat, 316 Stainless Steel Stem, PTFE Seal, 316 Stainless Steel Ball, -36 to 368 deg F, 2.45 in L Dimensions, Import, Additional Information: 3/8-18 Thread Size, 0.87 in Hex Size

Additional Information      :      3/8-18 Thread Size, 0.87 in Hex Size
Ball Material      :      316 Stainless Steel
Body Material      :      316 Stainless Steel
Connection Type      :      MIP x FIP
Dimensions      :      2.45 in L
Domestic/Import      :      Import
Inlet to Outlet Length      :      2.45 in
Nominal Size      :      3/8 in
Operator Type      :      Butterfly Handle
Port Type      :      Standard
Pressure Rating      :      1000 psi WOG, 150 psi WSP
Seal Material      :      PTFE
Seat Material      :      PTFE
Stem Material      :      316 Stainless Steel
Temperature Rating      :      -36 to 368 deg F
Top to Inlet Center      :      1-1/2 in
  • pdfCatalog https://cx1content.unilogcorp.com/cx1/view/api/asset/v1/dam/assets/ITEM/DOC/file/532/MIDLANDINDUSTRIES_46903SS_Catalog.pdf
