MIDLAND INDUSTRIES 941154LFD 941154LFD

MIDLAND INDUSTRIES 941154LFD Ball Valve with Drain, 3/4 in Nominal, FIP x FIP, 600 psi WOG Pressure

MIDLAND INDUSTRIES 941154LFD Ball Valve with Drain, 3/4 in Nominal, FIP x FIP, 600 psi WOG Pressure

MIDLAND INDUSTRIES 941154LFD Ball Valve with Drain, 3/4 in Nominal, FIP x FIP, 600 psi WOG Pressure 941154LFD

MIDLAND INDUSTRIES Ball Valve, 3/4 in Nominal, Connection Type: FIP x FIP, Full Port, 600 psi WOG, 2.28 in L Inlet to Outlet, 1.89 in Top to Inlet Center, Handle Operator, Lead-Free Forged Brass Body, PTFE Seat, Brass Stem, Plated Steel Handle Nut and Lock Washer Trim, PTFE Packing, Plated Steel Handle, Stainless Steel Ball, Lead-Free/Contains Lead: Lead-Free, -40 to 365 deg F, 4.488 in OAL x 2.579 in H, Additional Information: 150 psi WSP Service Pressure, 3/4-14 Thread Size, 29.92 inHg Vacuum Services, 0.750 lb Weight

Additional Information      :      150 psi WSP Service Pressure, 3/4-14 Thread Size, 29.92 inHg Vacuum Services, 0.750 lb Weight
Ball Material      :      Stainless Steel
Body Material      :      Lead-Free Forged Brass
Connection Type      :      FIP x FIP
Dimensions      :      4.488 in OAL x 2.579 in H
Handle Material      :      Plated Steel
Inlet to Outlet Length      :      2.28 in
Lead-Free/Contains Lead      :      Lead-Free
Nominal Size      :      3/4 in
Operator Type      :      Handle
Packing Material      :      PTFE
Port Type      :      Full
Pressure Rating      :      600 psi WOG
Seat Material      :      PTFE
Stem Material      :      Brass
Temperature Rating      :      -40 to 365 deg F
Top to Inlet Center      :      1.89 in
Trim Material      :      Plated Steel Handle Nut and Lock Washer
  • pdfCatalog https://cx1content.unilogcorp.com/cx1/view/api/asset/v1/dam/assets/ITEM/DOC/file/532/MIDLANDINDUSTRIES_940171LF_Catalog.pdf
