MIDLAND INDUSTRIES 941157LF 941157LF

MIDLAND INDUSTRIES 941157LF Ball Valve, 1-1/2 in, FIP, Brass, 600 psi WOG, 150 psi WSP

MIDLAND INDUSTRIES 941157LF Ball Valve, 1-1/2 in, FIP, Brass, 600 psi WOG, 150 psi WSP

MIDLAND INDUSTRIES 941157LF Ball Valve, 1-1/2 in, FIP, Brass, 600 psi WOG, 150 psi WSP 941157LF

MIDLAND INDUSTRIES Ball Valve, 1-1/2 in Nominal, FIP Connection, Full Port, 600 psi WOG, 150 psi WSP Pressure, 3.44 in Inlet to Outlet Length, 2.66 in Top to Inlet Center, Handle Operator, Brass Body, PTFE Seat, Brass Stem, Steel Trim, PTFE Packing Material, Steel Handle, Stainless Steel Ball, Lead-Free Lead-Free/Contains Lead, -40 to 365 deg F, 7.343 in OAL x 3.909 in H Dimensions, Import, Additional Information: 1-1/2-11-1/2 Thread Size, 29.92 inHg Vacuum Service

Additional Information      :      1-1/2-11-1/2 Thread Size, 29.92 inHg Vacuum Service
Ball Material      :      Stainless Steel
Body Material      :      Brass
Connection Type      :      FIP
Dimensions      :      7.343 in OAL x 3.909 in H
Domestic/Import      :      Import
Handle Material      :      Steel
Inlet to Outlet Length      :      3.44 in
Lead-Free/Contains Lead      :      Lead-Free
Nominal Size      :      1-1/2 in
Operator Type      :      Handle
Packing Material      :      PTFE
Port Type      :      Full
Pressure Rating      :      600 psi WOG, 150 psi WSP
Seat Material      :      PTFE
Stem Material      :      Brass
Temperature Rating      :      -40 to 365 deg F
Top to Inlet Center      :      2.66 in
Trim Material      :      Steel
  • pdfCatalog https://cx1content.unilogcorp.com/cx1/view/api/asset/v1/dam/assets/ITEM/DOC/file/532/MIDLANDINDUSTRIES_940171LF_Catalog.pdf
