MIDLAND INDUSTRIES 949169 2-Piece Ball Valve, 2-1/2 in Nominal, FIP, 1000 psi WOG Pressure, -60 to 450 deg F

MIDLAND INDUSTRIES 949169 2-Piece Ball Valve, 2-1/2 in Nominal, FIP, 1000 psi WOG Pressure, -60 to 450 deg F

MIDLAND INDUSTRIES 949169 2-Piece Ball Valve, 2-1/2 in Nominal, FIP, 1000 psi WOG Pressure, -60 to 450 deg F 949169

MIDLAND INDUSTRIES 2-Piece Ball Valve, 2-1/2 in Nominal, Connection Type: FIP, Full Port, 1000 psi WOG, Locking Handle Operator, Material Standard: ASTM A351 CF8M, 316 Stainless Steel Body, PTFE Seat, AISI 304 Stainless Steel Stem, PTFE Seal, AISI 304 Stainless Steel Nut and Washer, Gland Nut Trim, PTFE Packing, AISI 304 Stainless Steel Handle, 316 Stainless Steel Ball, -60 to 450 deg F, Import, Additional Information: 125 psi Steam Pressure, 1500 psi Hydrostatic Test Pressure, 2-1/2-8 Thread Size, 7.610 lb Weight

Additional Information      :      125 psi Steam Pressure, 1500 psi Hydrostatic Test Pressure, 2-1/2-8 Thread Size, 7.610 lb Weight
Ball Material      :      316 Stainless Steel
Body Material      :      316 Stainless Steel
Connection Type      :      FIP
Domestic/Import      :      Import
Handle Material      :      AISI 304 Stainless Steel
Material Standard      :      ASTM A351 CF8M
Nominal Size      :      2-1/2 in
Operator Type      :      Locking Handle
Packing Material      :      PTFE
Port Type      :      Full
Pressure Rating      :      1000 psi WOG
Seal Material      :      PTFE
Seat Material      :      PTFE
Stem Material      :      AISI 304 Stainless Steel
Temperature Rating      :      -60 to 450 deg F
Trim Material      :      AISI 304 Stainless Steel Nut and Washer, Gland Nut
  • pdfCatalog https://cx1content.unilogcorp.com/cx1/view/api/asset/v1/dam/assets/ITEM/DOC/file/532/MIDLANDINDUSTRIES_949109_Catalog.pdf
