Square D 8536SBO2V02SX11 Non-Reversing Starter, 600 VAC, 5 HP, Three Pole, 1NO-1NC Auxiliary Contacts

Type S NEMA motor starters are used for full voltage starting and stopping of AC squirrel cage motors. Type S motor starters have ratings up to 810 A. This 3-pole NEMA Size 0 non-reversing starter has an 18 A rating. NEMA Size 0 motor starters have 3-phase ratings of 3 hp at 200 and 230 VAC and 5 hp at 460 and 575 VAC. This non-reversing NEMA motor starter has a melting alloy type overload relay that uses Type B thermal units to sense over current conditions. This NEMA starter has a 5 kA maximum SCCR (Short Circuit Current Rating) per UL 508A when protected by an appropriate circuit breaker or fuse. Type S motor starters are available with replaceable coils in a wide variety of voltages. This starter has a 110/120 VAC 50/60 Hz operating coil wired for separate control. This NEMA starter is an open device without an enclosure. This starter is 6.77 in tall, 4.01 in wide and 4.22 in deep. A wide variety of accessories are available for Type S starters. This starter is supplied with one normally open and one normally closed external interlock. Type S non-reversing NEMA motor starters are UL listed and CSA certified.
Square D Non-Reversing Starter, 600 VAC, 5 hp HP Rating, 50/60 Hz, 3 ph, 3 Pole, Screw Clamp Connection Type, 1NO-1NC Auxiliary Contacts, NEMA 0, 6.81 in H x 4.01 in W x 4.22 in D
