Square D FAL36020 FAL36020

Square D FAL36020 Molded Case Circuit Breaker, 600 V, 20 Amp, 25 kA Interrupt, Three Pole, Thermal Magnetic Trip

Square D Legacy FAL36020 Molded Case Circuit Breaker, 600 V, 20 A, 25 kA Interrupt, 3 -Pole, Thermal Magnetic Trip

Square D Legacy FAL36020 Molded Case Circuit Breaker, 600 V, 20 A, 25 kA Interrupt, 3 -Pole, Thermal Magnetic Trip FAL36020

Square D Molded Case Circuit Breaker, Model: FA, 20 A, 600 V, 25 kA Interrupt Rating, 3 Poles, Lug Connection, 100 A Frame, Thermal Magnetic Trip, 14 to 4 AWG Copper, 12 to 4 AWG Aluminum Wire, Unit Mounting, 104 deg F, 4-1/2 in Width, 6.4 in Height, Additional Information: 4.13 in D, 275 A Magnetic Hold Current, 600 A Magnetic Tripping Current, ABC Phase Connection

Additional Information      :      4.13 in D, 275 A Magnetic Hold Current, 600 A Magnetic Tripping Current, ABC Phase Connection
Amperage Rating      :      20 A
Connection Type      :      Lug
Frame Type      :      100 A
Height      :      6.4 in
Interrupt Rating      :      25 kA
Model      :      FA
Mounting Type      :      Unit
Number of Poles      :      3
Temperature Rating      :      104 deg F
Trip Type      :      Thermal Magnetic
Voltage Rating      :      600 V
Width      :      4-1/2 in
Wire Size      :      14 to 4 AWG Copper, 12 to 4 AWG Aluminum
  • pdfInstruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_FAL36030_Instruction_Installation_Manual.pdf
  • pdfRoHS https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_FAL36030_RoHS.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_FAL36020_Specification_Sheet.pdf
