Square D QO115CP QO115CP

Square D QO115CP Miniature Circuit Breaker, 120/240 VAC/48 VDC, 15 Amp, 5 kA, 10 kA Interrupt, Single Pole

Square D QO™ Series QO115CP Mini Circuit Breaker, 120/240 VAC/48 VDC, 15 A, 5 kA, 10 kA Interrupt, 1-Pole

Square D QO™ Series QO115CP Mini Circuit Breaker, 120/240 VAC/48 VDC, 15 A, 5 kA, 10 kA Interrupt, 1-Pole QO115CP

QO circuit breakers come in plug-on or bolt-on options and a complete range of amperages and interrupting ranges to fit into various QO distribution panels. QO is the "World's Finest" industry leading offer since 1955, with features engineered for faster installation, reliability and quality.
Square D Mini Circuit Breaker, QO™ Series, 15 A, 120/240 VAC/48 VDC, 50/60 Hz, 5 kA, 10 kA Interrupt Rating, 1 Poles, 1 ph Phase, Pressure Plate Connection, 1-Space Frame, Fixed Trip, 14 to 8 AWG Wire, Plug-In Mounting, 40 deg C, 3/4 in Width, 2.91 in Length, 2.99 in Height

Amperage Rating      :      15 A
Connection Type      :      Pressure Plate
Frame Type      :      1-Space
Frequency Rating      :      50/60 Hz
Height      :      2.99 in
Interrupt Rating      :      5 kA, 10 kA
Length      :      2.91 in
Mounting Type      :      Plug-In
Number of Poles      :      1
Phase      :      1 ph
Series      :      QO™ Series
Temperature Rating      :      40 deg C
Trip Type      :      Fixed
Voltage Rating      :      120/240 VAC/48 VDC
Width      :      3/4 in
Wire Size      :      14 to 8 AWG
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_HOM115CP_Catalog.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_QO115CP_Specification_Sheet.pdf
