Square D QO125CP Miniature Circuit Breaker, 120/240 VAC/48 VDC, 25 Amp, 5 kA, 10 kA Interrupt, Single Pole

QO and QOB one, two and three-pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and DC systems. These circuit breakers have an overcenter, trip-free toggle mechanism with quick make, quickbreak action and positive handle indication They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This QO miniature breaker is rated as 25 A, 120/240 V and one-pole. This unit provides 10 kA breaking capacity and plug-in mounting. A full line of factory installed accessories, such as shunt trips, auxiliary switches and alarm switches, is also available QO breakers use a compact 3/4 in W design for small system footprint. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555 This product is shipped with commercial packaging.
Square D Circuit Breaker, QO™ Series, 25 A, 120/240 VAC/48 VDC, 50/60 Hz, 5 kA, 10 kA Interrupt Rating, 1 Poles, Pressure Plate Connection, 14 to 8 AWG Wire, Plug-In Mounting, 40 deg C, 3/4 in Width, 2.91 in Length, 2.99 in Height

• Catalog https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_QO1515CP_Catalog.pdf
• Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_QO125CP_Specification_Sheet.pdf
• Video Link https://www.youtube.com/embed/BN-HQQVJQuY
