Square D QO260CP QO260CP

Square D QO260CP Miniature Circuit Breaker, 120/240 VAC/48 VDC, 60 Amp, 5 kA, 10 kA Interrupt, Double Pole

Square D QO™ Series QO260CP Mini Circuit Breaker, 120/240 VAC/48 VDC, 60 A, 5 kA, 10 kA Interrupt, 2-Pole

Square D QO™ Series QO260CP Mini Circuit Breaker, 120/240 VAC/48 VDC, 60 A, 5 kA, 10 kA Interrupt, 2-Pole QO260CP

QO circuit breakers come in plug-on or bolt-on options and a complete range of amperages and interrupting ranges to fit into various QO distribution panels. QO is the "World's Finest" industry leading offer since 1955, with features engineered for faster installation, reliability and quality.
Square D Mini Circuit Breaker, QO™ Series, 60 A, 120/240 VAC/48 VDC, 50/60 Hz, 5 kA, 10 kA Interrupt Rating, 2 Poles, 1 ph Phase, Box Lug Connection, 2-Space Frame, 8 to 2 AWG Wire, Plug-In Mounting, 40 deg C, 1-1/2 in Width, 2.91 in Length, 3.11 in Height

Amperage Rating      :      60 A
Connection Type      :      Box Lug
Frame Type      :      2-Space
Frequency Rating      :      50/60 Hz
Height      :      3.11 in
Interrupt Rating      :      5 kA, 10 kA
Length      :      2.91 in
Mounting Type      :      Plug-In
Number of Poles      :      2
Phase      :      1 ph
Series      :      QO™ Series
Temperature Rating      :      40 deg C
Voltage Rating      :      120/240 VAC/48 VDC
Width      :      1-1/2 in
Wire Size      :      8 to 2 AWG
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_HOM115CP_Catalog.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_QO260CP_Specification_Sheet.pdf
