Square D QOU260 QOU260

Square D QOU260 Miniature Circuit Breaker, 120/240 VAC/48 VDC, 60 Amp, 5 kA, 10 kA Interrupt, Double Pole

Square D QOU260 Circuit Breaker, 120/240 VAC/48 VDC, 60 A, 5 kA, 10 kA Interrupt, 2-Pole

Square D QOU260 Circuit Breaker, 120/240 VAC/48 VDC, 60 A, 5 kA, 10 kA Interrupt, 2-Pole QOU260

Square D Circuit Breaker, 60 A, 120/240 VAC/48 VDC, 5 kA, 10 kA Interrupt Rating, 2 Poles, 1 ph Phase, Slotted Box Lugs Connection, 14 to 2 AWG Aluminum/Copper Wire, Bolt-On Mounting, 40 deg C, 1-1/2 in Width, 2.95 in Length, 4.05 in Height

Amperage Rating      :      60 A
Connection Type      :      Slotted Box Lugs
Height      :      4.05 in
Interrupt Rating      :      5 kA, 10 kA
Length      :      2.95 in
Mounting Type      :      Bolt-On
Number of Poles      :      2
Phase      :      1 ph
Temperature Rating      :      40 deg C
Voltage Rating      :      120/240 VAC/48 VDC
Width      :      1-1/2 in
Wire Size      :      14 to 2 AWG Aluminum/Copper
  • HACR and switching duty rated circuit breaker application
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_QOU260_Catalog.pdf
  • pdfInstruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Square_D_QOU260_Instruction_Installation_Manual.pdf
