Timken® 203PP 203PP

Timken 203PP Deep Groove Radial Ball Bearing, 17 MM Diameter Bore, 40 MM OD, 0.472 Inch Width, Single Row

Timken® Light 200K Series 203PP Radial Ball Bearing, 17 mm Dia Bore, 40 mm OD, 0.472 in W, 1 -Row

Timken® Light 200K Series 203PP Radial Ball Bearing, 17 mm Dia Bore, 40 mm OD, 0.472 in W, 1 -Row 203PP

Bearings in the 200 Series have a greater section height than the Extra Light 9300 and 9100 Series bearings and feature a close dimensional balance between bore, outside diameter and width. These characteristics make them well-suited for a broad range of applications involving light to medium loads combined with relatively high speeds. Their versatility has made them a popular design choice of designers and has resulted in many variations in the series. Snap ring combinations are also included.
Timken® Radial Ball Bearing, Series: Light 200K Series, 1 Rows, Double Sealed Seal/Shield Type, 17 MM Bore Diameter, 40 MM OD, 0.472 Inch Width, +0.0000 to -0.0003 Inch Tolerance, 2450 lb Dynamic Load Capacity, 1060 lb Static Load Capacity

Bore Diameter      :      17 mm
Dynamic Load Capacity      :      2450 lb
Number of Rows      :      1
Outside Diameter      :      40 mm
Seal/Shield Type      :      Double Sealed
Series      :      Light 200K Series
Static Load Capacity      :      1060 lb
Tolerance      :      +0.0000 to -0.0003 in
Width      :      0.472 in
  • Conrad-type bearing is well-balanced, with deep races and uninterrupted race shoulders
  • Excellent, general-purpose bearing
  • Capacity to carry radial and thrust in either direction or combined loads
  • Electric motor quality for applications where quietness is a requirement
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Timken_200KDD_Catalog.pdf
