Timken® 332-2 332-2

Timken 332-2 Tapered Roller Bearing Cup, 1-5/8 Inch Diameter Bore, 3.149 Inch OD, 0.826 Inch Width, Single Row

Timken® 335 Series 332-2 Tapered Roller Bearing Cup, 1-5/8 in Dia Bore, 3.149 in OD, 1-Row, 0.826 in W Bearing

Timken® 335 Series 332-2 Tapered Roller Bearing Cup, 1-5/8 in Dia Bore, 3.149 in OD, 1-Row, 0.826 in W Bearing 332-2

This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts - the cone (inner ring) assembly and the cup (outer ring). It is typically mounted in opposing pairs on a shaft.
Timken® Tapered Roller Bearing Cup, Series: 335 Series, 1-5/8 Inch Bore Diameter, 3.149 Inch OD, 0.826 Inch Bearing Width, 0.05 Inch Fillet Radius, 5490 lbf, 21200 lbf, 18700 lbf, 2570 lbf Load, 1 Rows, Steel Cage Material, 0.701 Inch Width

Bearing Width      :      0.826 in
Bore Diameter      :      1-5/8 in
Cage Material      :      Steel
Dimensions      :      0.701 in W
Fillet Radius      :      0.05 in
Load Capacity      :      5490 lbf, 21200 lbf, 18700 lbf, 2570 lbf
Number of Rows      :      1
Outside Diameter      :      3.149 in
Series      :      335 Series
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Timken_332_2_Catalog.pdf
