Timken® 615-5M-15 615-5M-15

Timken 615-5M-15 Synchronous Drive Belt, 15 MM Width Top, Fiberglass

Timken® 615-5M-15 Synchronous Drive Belt, 15 mm W Top, Fiberglass

Timken® 615-5M-15 Synchronous Drive Belt, 15 mm W Top, Fiberglass 615-5M-15

Synchro-Cog HT is a curvilinear synchronous belt with an HTD profile. Although HT stands for high-torque, the evolution of synchronous belts makes Synchro-Cog HT a medium torque belt. Synchro-Cog HT belts are made of treated fiberglass cord to assure length stability and high tensile strength. The teeth are precisely formed and accurately spaced for smooth, uniform transfer of power. The rubber backing provides resistance to ozone, grease, heat build-up, sunlight and flex fatigue.
Timken® Synchronous Drive Belt, 15 MM W Top, 615 MM Pitch Length, Synchro-Cog® HT, Fiberglass Cord Reinforced, Fiberglass, Domestic, For Use With MPB, QD, Taper Bushed (5 MM) High Torque Synchronous (HTS) Sprockets, 123 Teeth, 5 MM Pitch

Additional Information      :      123 Teeth, 5 mm Pitch
Construction      :      Synchro-Cog® HT
Domestic/Import      :      Domestic
Material      :      Fiberglass
Pitch Length      :      615 mm
Reinforced Material      :      Fiberglass Cord
Suitable For Use With      :      MPB, QD, Taper Bushed (5 mm) High Torque Synchronous (HTS) Sprockets
Top Width      :      15 mm
  • Fiberglass cord is treated to assure length stability, flexibility and high tensile strength
  • Rubber teeth are precisely formed and accurately spaced for smooth, uniform transfer of power
  • Rubber backing provides resistance to ozone, grease, heat build-up and flex fatigue
  • Nylon fabric cover provides resistance to tooth wear and shear
  • Economical
  • Maximum drive efficiency
