Timken 9104PP Deep Groove Radial Ball Bearing, 20 MM Diameter Bore, 42 MM OD, 0.472 Inch Width, Single Row

Radial ball bearings consist of an inner and outer ring with a cage containing a complement of precision balls. The standard Conrad-type bearing has a deep groove construction capable of handling radial and axial loads from either direction in versatile designs that permit relatively high-speed operation. In addition to standard single row deep groove bearings, Timken® offers special designs, including a maximum capacity series and an extra large (XLS) radial series bearing.
Timken® Deep Groove Ball Bearing, Series: Extra Light 9100K Series, 1 Rows, Double Sealed Seal/Shield Type, 20 MM Bore Diameter, 42 MM OD, 0.472 Inch Width, +0.0000 to -0.0004 Inch Tolerance, 2340 lbf Dynamic Load Capacity, 1130 lbf Static Load Capacity, Maximum Speed: 11290 rpm, Steel Bearing Material

• For applications where housing diameters are restricted and it is desirable to maintain relatively large shaft diameters
• Electric motor quality for applications where quietness is a requirement

• Catalog https://assets.unilogcorp.com/267/ITEM/DOC/Timken_302KDD_Catalog.pdf
• Line Drawing https://assets.unilogcorp.com/267/ITEM/DOC/Timken_9104PP_Line_Drawing.pdf
